Технические данные
Control: SYNTEC 200TB (NEW 2019)
Technical data
Working range:
Module from: 1
up to: 5
Max. wheel diameter: 250 mm
Max. gear cutting width: 70 mm
Table diameter: 320 mm
Drill diameter of the table: 125 mm
Max. ram stroke: 100 mm
Distance ram to table:
from: 190 mm
up to: 290 mm
Taper in ram: 40 ISO
Ram stroke speeds:
from: 100 s/min
up to: 1200 s/min
Voltage 50 Hz 3x: 380 Volt
Drive: 36 kW
Machine's weight about: 10000 kg
Overall dimensions machine:
Length: 4500 mm
Width: 3200 mm
Height: 2900 mm
Equipment:
Retrofited control: 2019
Helical gearing
Mise en conformité CE
