Dane techniczne
Technical data
Min. diameter threaded: 4 mm
Max. diameter threaded: 20 mm
Min. pitch: 0.5 mm
Max. pitch: 2.5 mm
Max. roll die diameter: 118 mm
Roll die width: 50 mm
Shaft distance:
min.: 100 mm
max: 135 mm
Shaft diameter: 40 mm
Roll speeds:
up to: 80 rpm
Voltage 50 Hz 3x: 380 Volt
Motor power: 2 kW
Machine's weight about: 750 kg
Overall dimensions machine:
Length: 1170 mm
Width: 740 mm
Height: 1050 mm
Various accessories:
Set of thread rolls
Lamp
Set of service tools
