Technische gegevens
Technical data
Table length: 900 mm
Table width: 250 mm
Grinding length: 650 mm
Grinding width: 375 mm
Grinding height: 300 mm
Table load max.: 280 kg
Execution:
hydraulic
Longitudinal travel (X-axis): 700 mm
Transversal travel (y axis): 350 mm
Automatic cross-feed:
stepless
from: 3 mm/stroke
up to: 50 mm/stroke
Table speeds:
stepless
from: 2 m/min
up to: 30 m/min
Diameter of grinding wheel: 300 mm
Width of the grinding wheel: 50 mm
Wheel int. diameter: 76.2 mm
Grinding wheel speeds:
number (steps): 2
from: 1500 rpm
up to: 3000 rpm
Voltage 50 Hz 3x: 380 Volt
Grinding spindle motor: 3.7/4.5 kW
Machine's weight about: 4000 kg
Overall dimensions machine:
Length: 2800 mm
Width: 2300 mm
Height: 2400 mm
Various accessories:
Coolant system
Magnetic separator
Electrical magnetic chuck
Length: 600 mm
Width: 300 mm
Central lubrification
