Technische gegevens
Technical data
Table length: 550 mm
Table width: 320 mm
Longitudinal travel (X-axis): 400 mm
Transversal travel (y-axis): 250 mm
Vertical travel (z axis): 400 mm
Table load max.: 400 kg
Drill capacity in steel: 20 mm
Taper in spindle: MT: 2
Stroke of drilling spindle (Z-axis): 130 mm
Bore diameter max.: 75 mm
Distance table to spindle: 590 mm
Spindle speeds:
stepless
from: 60 rpm
up to: 3000 rpm
Feeds:
Drill spindle slide:
number (steps): 2
from: 0.03 mm/r
up to: 0.06 mm/r
Voltage 50 Hz 3x: 380 Volt
Spindle motor: 0.80 HP
Machine's weight about: 1100 kg
Overall dimensions machine:
Length: 1200 mm
Width: 1150 mm
Height: 1650 mm
Various accessories:
Lamp
