Technische gegevens
Control: ELB STC touch screen
Operating hours: 1000
Technical data
Table length: 1360 mm
Table width: 590 mm
Axial motion:
Longitudinal travel (X-axis): 1100 mm
Cross travel (z-axis): 560 mm
vertical travel (Y-axis)
Table load max.: 1000 kg
Grinding length: 1000 mm
Grinding width: 600 mm
Grinding height over table: 640 mm
Grinding wheel:
Diameter: 400 mm
Width: 100 mm
Bore: 127 mm
Grinding wheel speeds:
stepless
from: 1000 rpm
up to: 3000 rpm
Table speeds:
stepless
from: 2 m/min
up to: 30 m/min
Automatic cross feed:
from: 0.001 mm/min
up to: 2000 mm/min
Automatic vertical feed:
from: 0.001 mm/min
up to: 1500 mm/min
Vertical rapid traverse: 0.6 m/min
Voltage 50 Hz 3x: 400 Volt
Grinding spindle motor: 15 kW
Machine's weight about: 6300 kg
Various accessories:
Paper filter facility
Magnetic plate:
Length: 800 mm
Width: 600 mm
Set of grinding wheels
Set of flanges
Handwheel electroinic
