Technische gegevens
Control: HEIDENHAIN TNC 640
Technical data
Number of axis simultaneous: 5
Rotary table:diameter: 150 mm
Table load max.: 25 kg
Longitudinal travel (X-axis): 400 mm
Transversal travel (y-axis): 200 mm
Vertical travel (z axis): 385 mm
B axis swivelling range: -110 / +30 °
Table speeds:
stepless
up to: 4000 rpm
Holding torque of the table: 400 Nm
Tool changer:
Number of tools: 96
Tool diameter max.: 50 mm
Tool lenght: 130 mm
Max. tool-weight: 1 kg
Time of tool changing: 0.8 sec
Average chip-to-chip time: 3 sec
Spindle nose: HSK: E40
Spindle speeds:
stepless
up to: 42000 rpm
Rapid traverse:: 60 m/min
Acceleration: 10 m/s
Air connect: 6 bar
Voltage 50 Hz 3x: 400 Volt
Spindle power: 10 / 15 kW
Torque max.: 8 / 12 Nm
Machine's weight about: 4700 kg
Overall dimensions machine:
Length: 2210 mm
Width: 1750 mm
Height: 2220 mm
Various accessories:
Paper filter facility
Infrared measuring sensor
Laser tool setting system
Chip conveyor
Lamp
Oil mist extractor
