Mikron - VCP 600-HS

Mikron - VCP 600-HS
  • Mikron - VCP 600-HS
  • Mikron - VCP 600-HS
  • Mikron - VCP 600-HS
  • Mikron - VCP 600-HS
  • Mikron - VCP 600-HS
  • Mikron - VCP 600-HS
  • Mikron - VCP 600-HS
  • Mikron - VCP 600-HS
  • Mikron - VCP 600-HS

Prijsaanvraag
  • MerkMikron
  • Type/ModelVCP 600-HS
  • Voorraad nummer21747
  • Bouwjaar2001
  • Verkoopprijs€ 000
  • WebsiteVCP 600-HS

Technische gegevens

  • Langs X mm
  • Dwars Y mm
  • Vertikaal Z mm
  • Max. spilsnelheid rpm
  • Max. voeding mm/min
  • Posities ATC
  • Aantal pallets
  • CNC Merk
  • CNC Model


Control: HEIDENHAIN TNC 426/430
Operating hours: 43291
Technical data
Number of axis total: 3
Table length: 850 mm
Table width: 530 mm
Number of T-channels: 6
Distance of the T-slots: 63 mm
T-channel width: 14H12 mm
Table load max.: 400 kg
Longitudinal travel (X-axis): 600 mm
Transversal travel (y-axis): 450 mm
Vertical travel (z axis): 450 mm
Tool changer:
Number of tools: 36
Spindle nose: HSK: E40
Spindle speeds:
stepless
up to: 42000 rpm
Voltage 50 Hz 3x: 400 Volt
Total power required: 40 kW
Time under power: 62694 Hour
Operating time: 43291 Hour
Working time: 53367 Hour
Spindle run time: 1304 Hour
Noise level: 75 dB (A)
Machine's weight about: 6500 kg
Overall dimensions machine:
Length: 2500 mm
Width: 1600 mm
Height: 2600 mm
Various accessories:
Set of toolholders
Coolant system
3D measuring feeler gauge
Chip conveyor
Handwheel electroinic
Oil mist extractor
Spindle changed: 2017

Handelaar: MULLER MACHINES SA

MULLER MACHINES SA
Prijsaanvraag
