Technische gegevens
Control: CNC 311
Technical data
Table length: 770 mm
Table width: 630 mm
Table load max.: 500 kg
Longitudinal travel (X-axis): 650 mm
Transversal travel (y-axis): 450 mm
Verticla travel (W-axis): 500 mm
Max. grinding diameter: 230 mm
with display-plate: 360 mm
Stroke of spindle-nose: 125 mm
Max. angle with taper grinding:
up to: 16 °
up to grinding depth: 44 mm
Alternating stroke mouvement, infinitely adjust.
from Vmin.: 0.5 mm/min
up to Vmax.: 12000 mm/min
Stroke frequency Z: 4 Hz
Radiale fine feed U-axis up to: 5.5 mm
Planetary motion speeds: c axis
stepless
from: 5 rpm
up to: 250 rpm
Possible grinding-spindle speeds:
stepless
from: 4500 rpm
up to: 80000 rpm
With air-turbine max.: 160000 rpm
Voltage 50 Hz 3x: 380 Volt
Machine's weight about: 5600 kg
Overall dimensions machine:
Length: 2650 mm
Width: 2000 mm
Height: 3150 mm
