Technische gegevens
Control: GE FANUC Series O-M
Technical data
1 column execution
Table:
Table length: 600 mm
Table width: 380 mm
T-channel width: 10 mm
Number of spline: 6
Distance of the T-slots: 50 mm
Table load max.: 200 kg
Carriage:
Longitudinal travel (X-axis): 500 mm
Transversal travel (y-axis): 300 mm
Travel of the vertical slide: 450 mm
Passage from grinding motor to table: 485 mm
Max. grinding diameter: 230 mm
with display-plate: 360 mm
Stroke of spindle-nose: 340 mm
Max. angle with taper grinding:
up to: 16 °
Vertical travel of grinding spindle:
stepless from: 1 mm
up to: 110 mm
Travel speeds:
stepless
from: 0.5 m/min
up to: 12 m/min
Planetary motion speeds: c axis
stepless
from: 5 rpm
up to: 250 rpm
Feeds:
X axis: 0 - 12 m/min
Y axis: 0 - 12 m/min
W axis: 900 mm/min
Voltage 50 Hz 3x: 380 Volt
Spindle motor: 7.5 kW
Machine's weight about: 4000 kg
Overall dimensions machine:
Length: 2700 mm
Width: 1700 mm
Height: 2850 mm
