Mazak - Integrex 400 III-S

Mazak - Integrex 400 III-S
  • Mazak - Integrex 400 III-S
  • Mazak - Integrex 400 III-S
  • Mazak - Integrex 400 III-S
  • Mazak - Integrex 400 III-S
  • Mazak - Integrex 400 III-S
  • Mazak - Integrex 400 III-S
  • Mazak - Integrex 400 III-S

Prijsaanvraag

Technische gegevens

  • Draaidiameter420 mm
  • Draailengte1524 mm
  • Posities revolverkop1
  • Posities ATC40
  • Aantal gestuurde assen6
  • CNC MerkMazatrol
  • CNC Model640 MT PRO

Stock No.: 3963
CNC LATHE
Manuf.: MAZAK, Type: INTEGREX 400 III-S
Serial No.: 173882, Build: 2005

Specifications:

Max. Turning diameter      420 mm dia.
Max. Turning dia o/slide    850 mm dia.
Turning Length              1524 mm
Main motor power            30 kw
Main Spindle speed Range    3300 rpm
Boring trough drawing pipe 102 mm dia.
C Axis - Mainspindle Stroke 0.001 degree
Y axis                      +/- 115 mm
B axis Stroke              -30/+195 Degree
B axis spindrel rpm.        12000 rpm
B axis milling power        18.5 kw
B axis system              Capto C6
Sub Spindle
C Axis – Sub spindle Stroke 0.001 degree
Motor Power Subspindle      26/22 Kw
Total Power Source          99.9 kva
Control system              Mazatrol 640  manuf.
Working hours Spindle      7167 Hours
Controlled in              6 Axis
Accessories:
ATC Tool magazine with      40 Stations
Hydr. Chuck Mainspindle    300 mm dia
Hydr. Chuck Supspindle      300 mm dia
Various toolposts.
Tool setter
Delivery time              Feb. 2025

Length: 5100 mm, Height: 2798 mm, Width: 2200 mm, Weight: 13300 kg

Handelaar: DENTOOL LTD

DENTOOL LTD
Prijsaanvraag
