Technische gegevens
Control: HEIDENHAIN TNC 426
Operating hours: 45357
Technical data
Table length: 1200 mm
Table width: 600 mm
Longitudinal travel (X-axis): 710 mm
Transversal travel (y axis): 630 mm
Vertical travel (z axis): 500 mm
Spindle speeds:
up to: 6300 (42'000*) rpm
Tool changer:
number of tools: 20
Feeds:
longitudinal from: 0 mm/min
up to: 15000 mm/min
transversal from: 0 mm/min
up to: 15000 mm/min
vertical from: 0 mm/min
Milling spindle motor: 11 kW
Machine's weight about: 4690 kg
Overall dimensions machine:
Length: 4700 mm
Width: 2100 mm
Height: 2700 mm
Various accessories:
Rigide table
High frequency spindle: 42000* rpm
Manufacturer: FISCHER
Set of toolholders
Oil mist extractor: FIBARON
Handelaar: MULLER MACHINES SA
Prijsaanvraag
