Technische gegevens
Control: FANUC Series Oi-TD
Operating hours: 6000
Technical data
Number of spindles: 4
Min. grinding diameter: 3 mm
Max. grinding diameter: 200 mm
Workpiece length max.: 600 mm
Swing diameter:
Above the workpiece table: 230 mm
In front of the workpiece table: 350 mm
Centre height: 130 mm
Centre height over slide: 200 mm
Axial motion:
Longitudinal travel (Z-axis): 500 mm
Cross travel (x-axis): 120 mm
Spindle head (u axis): 150 mm
Feed range:
Z axis (longitudinal travel): 0 - 99.99 mm/min
X axis (transversal): 0 - 99.99 mm/min
Rapid traverse Z: 15 m/min
Rapid traverse X: 5 m/min
B axis swivelling range: -32 / + 2 °
Resolution: 0.0001 °
Grinding spindle head:
Resolution: 0.001
Air connect: 5 bar
Voltage 50 Hz 3x: 380 Volt
Grinding spindle motor: 4.3 / 4.8 kW
Machine's weight about: 4500 kg
Various accessories:
Retrofited control: 2014
Wheel truieng attachment hydraulic
Coolant system
Paper filter facility
Suction plant
Set of grinding arbor
Set of flanges for internal grinding
Lamp
Tool cabinet
Three-jaw bezel folds open
Internal grinding spindle:
number: 4
max. speed: 7500 rpm
max. speed: 18000 rpm
max. speed: 24000 rpm
max. speed: 30000 rpm
