Données techniques
Manufacturing origin JP
Voltage 400 V
Netweight 1950 kg
Custom position 8458.9120
Dimensions 165x120x173 cm
Fanuc Oi-TD, Ø20 mm.,Length 210 mm.,X1,Z1,Y1,X4,Z4,
sub-spindle, driven tools, 12000min-1,bore20, feeder SBF 320
TECHNICAL DATA
Number of axes 5
Number of spindles 2
MAIN SPINDLE
Maximal bar diameter Ø 20 [mm]
Maximal machining length 170 [mm]
Spindle speed 10000 [rpm]
Spindle power 3.7 [kW]
C-axis indexing precision 0.001 [°]
COUTER-SPINDLE
Maximum bar diameter Ø 20 [mm]
Z-travel
Spindle speeds 12000 [rpm]
Spindle power 2.2 [kW]
C-axis indexing precision 1 [°]
Number of platen 1
PLATEN 1
Number of positions 8
Number of driven positions 3
Speed of driven tools 8000 [rpm]
END ATTACHMENT
Number of positions 4
BACK OPERATION
Number of positions 7
ELECTRIC SUPPLY
Tension 400 [V]
Installed power 11 [kW]
SPACE REQUIRED
Dimensions on floor 1640 x 1200 [mm]
Height 1725 [mm]
Weight 1950 [kg
errors and omissions excepted-data given without obligation
Marchand: SCEMAMA SA
