Données techniques
INFORMATION
Manufacturing origin : Switzerland
Voltage : 400V/50Hz/3ph ; 8 KVA ; 12A
Netweight : abt. 1500 kg
Dimensions : 1650x1050x1850 mm
Custom position : 8458.11 20
TECHNICAL DATA
(standard execution)
Headstock (axis Z1) (+C axis optional)
Bar capacity of max bar : dia. 10 mm
Max workpiece length according to guide bush type : 60/90 mm
Rotation speed of the programmable spindle : 0-16000 min-1
Positioned stopping and indexing increment : 0,1°
Max spindle power : 1,1 (3,7) kW
Guide-bush holder (X1/Y1) (X2/Y2)
Number of tools on guide bush (2 slides ; 2 x 2 axis) : 2 x 4
Cross section of tools : 8 x 8 mm
Number of cross drilling/milling attachment on guide bush : 4
Programmable rotation speeds : 0-12000 min-1
End attachment (X3/Y3)
Max number of end tools : 3
Programmable rotation speed : 0-12000 min-1
Opposite spindle and counter-operation (X4/Z4) (C-axis optional)
Clamping capacity max diameter : 7 mm
Programmable rotation speed : 0-16000 min-1
Positioned stopping and idexing increment : 0,1°
Max number of counter – operations : 4
Number of stationary or revolving spindles : 4
Max spindle rotation speed : 9000 min-1
System and drives Tornos-Bechler/Fanuc
processor : 486 DX2
Number of simultaneous axes : 10
