Données techniques
INFORMATION
Completely rebuilt in 2023
Manufacturing origin : CE – France
Voltage : 380/50/3
Netweight : 1700 kg
Custom position : 8460.2920
Dimensions : 1800×1300 mm
TECHNICAL DATA
Diameter capacity : up to 50 mm
Grinding wheel :
Diameter : 350 mm
Width : 100 mm
Bore : 127 mm
Recesses : 2x 200×15 mm
Driving wheel :
Diameter : 230 mm
Width : 100 mm
Bore : 76 mm
Recesses : 2x127x15 mm
Power of grinding-wheel : 7,5 or 10 HP
Power of driving-wheel : : 1,1 HP
Speed of grinding-wheel : 2’720 min-1
Speed of driving-wheel : 10 – 200 U/mn
Tilting of driving-wheel : -8 to +8° (vertical)
: -2 to +4° (horizontal)
Speed of grinding-wheel’s diamond : 50 – 250 mm/min
Capacity coolant tank : 250 L
Capacity pump : 50 L / min
Wheel’s center height from the floor : 1000 mm
errors and omissions excepted data gived without obligation
