Données techniques
Hydraulic press two uprights GIGANT G2-800/2
Press general characteristics
- Total press power 800+350 tons
- Pistons: 2 ton 800
- Return power ton 100
- Moving table or piston stroke mm 1000
- Max working pressure Bar 250
- Pump l/min. 260
- Moving table approach speed mm/1'' 300
- Moving table working speed mm/1'' 3-9
- Moving table return speed mm/1'' 130
- Electric motors: 1 kW 75
- Number of revolutions per minute g/1' 1000
- Voltage Volt 380/660 Hz 50
- Max light between the clouds mm 1600
- Light between uprights mm 3720
- Fixed working table dimensions mm 3700x2700
- Mobile table dimensions mm 3700x2700
- Sheet press: 6 ton 350
- Plate holder stroke mm 400
- Max working pressure Bar 240
- Plate holder table size mm 3200x2200
- Overall dimensions of the press mm 7200x3600x9000
- Approximate press weight Kg 162.000
