Données techniques
CENTERS DISTANCE 5.867 MM.
MIN. / MAX. WORKING Ø 76,2
/ 1.574 MM.
MAX WEIGHT BETWEEN CENTERS (without steadies) 60.000 KG.
WHEEL MOTOR POWER 40 HP.
WHEEL Ø 914 MM.
WHEEL WIDTH 102 MM.
WORKPIECE SPEEDS 6
÷ 32 RPM.
LONGITUDINAL WHEEL TRAVEL 6.477 MM.
TRANSVERSAL WHEEL TRAVEL 635 MM.
TOTAL WEIGHT 120 TONS.
BUILT IN 1970
COMPLETE WITH :
- N. 5 OPEN STEADIES
- CROWNING
- GAUGES Ø 400 ÷ 1.600 MM.
- WHEELS AND WHEEL FLANGES
- WATERTANK WITH FILTER
Marchand: NUOVA LOMBARMET SPA
