Données techniques
TABLE 2.700 x 700 MM.
TABLE LONGITUDINAL TRAVEL (X) 2.500 MM.
TABLE TRANSVERSAL TRAVEL (Z) 1.200 MM.
HEAD VERTICAL TRAVEL (Y) 1.500 MM.
RAM TRAVEL (W) 500 MM.
SPINDLE TAPER ISO 50
SPINDLE MOTOR POWER 17 KW.
SPINDLE SPEEDS 20 ÷ 2.000 RPM.
MAX. WEIGHT ON TABLE 4 TONS.
CNC HEIDENHAIN TNC 407
TOTAL WEIGHT 15,5 TONS.
BUILT IN 1991
COMPLETE WITH:
- “ TABONI “ CNC ROTARY TABLE: 770 x 770 MM.; CAPACITY 4.000 KG.; 720 POSITIONS
- AUTOMATIC HORIZONTAL / VERTICAL MILLING HEAD
Marchand: NUOVA LOMBARMET SPA
Demande de prix
