Données techniques

  • Epaisseur de la tôle 10,00 mm
  • Largeur de la tôle3060 mm
  • Course butée arrière1000 mm

MORGAN RUSHWORTH BHG3 3100 x 10 Hydraulic Guillotine with Cybelec CybTouch 8 NC Controller.Year 2013
Cutting Length 3060mm. Cutting Capacity (45 Kg/mm2) 10mm. Cutting Capacity (70 Kg/mm2) 6mm. Cutting Angles 2. Max Stroke Per Minute 12. No. of Hold Downs 17. Main Motor 22kW. Backgauge Motor 0.37kW. Nominal Power (excluding options) 23.9kW. Backgauge Travel 1000mm. Hydraulic Oil Capacity 170 litres. Table Length 3420 mm. Throat Depth 250mm. Table Working Height  800mm.
Machine dimensions L x W x H 3850mm x 1775mm x 1850mm. Approximate weight 9200kg.
