MG - AR 140

• Print
• Add to favorites

• BrandMG
• Type/ModelAR 140
• Stock Number8642
• Year2007
• WebsiteAR 140

Technical details

• Rounds3 mm
• Squares390 mm
• Flats1 mm
• Flats on edge1 mm
• Angles1 mm
• (1) horizontal / (2) vertical2

Profile bending machineMG - AR 140

Roll diameter 390 mm
2 sets off rolls included
Hydraulic side support Left Right
Manuel or NC-Cycle controlled


Horizontal and vertical:Yes, Horizontal + Vertical
Shaft Ø:               140mm
Number of rolls:       3
Stroke X-Axis:         400mm
Resistance moment:     130CM³
Capacity flat:         220 x 50 x R=2000mm
Capacity Tube:         180 x 4 x R=4000Ø x mm
Capacity bar:          80 x 80 x R=1000mm
Capacity HEA-Profile:  180 x R=1800mm
Working speed:         0 - 5000mm/min.
Adjustment siderolls:  Hydraulic
Length:                2100mm
Width:                 1900mm
Height:                2100mm
Weight:                6500kg

Dealer: MACH4METAL BV

Price request
