Technical details
Technical data
Table length: 1100 mm
Table width: 305 mm
Longitudinal travel (X-axis): 700 mm
Transversal travel (y axis): 250 mm
Vertical travel (z axis): 490 mm
Spindle speeds:
number (steps): 18
from: 38 rpm
up to: 1510 rpm
Taper in spindle: 40 ISO
Feeds steps:: 18
longitudinal from: 12.0 mm/min
up to: 1050 mm/min
transversal from: 12.0 mm/min
up to: 1050 mm/min
vertical from: 6.0 mm/min
up to: 525 mm/min
Rapid traverse:
longitudinal: 3.5 m/min
transversal: 3.5 m/min
vertical: 1.7 m/min
Voltage 50 Hz 3x: 380 Volt
Motor output: 5.5 HP
Total power required: 7.5 HP
Machine's weight about: 2100 kg
Overall dimensions machine:
Length: 1800 mm
Width: 1600 mm
Height: 1800 mm
Various accessories:
Coolant system
Cam control
Steady
Set of collets
Set of short cutter arbors
Set of toolholders
Tool cabinet
Chucking clamp
Dealer: MULLER MACHINES SA
Price request
