Technical details
Equipped with:
Fanuc Control
Pallet Changer
12,000 RPM Spindle
Blum Tool Break Detection
Renishaw OMI-2 Probing
Chip Blaster High Pressure Coolant System
Chip Conveyor
Hydraulic Fixture Clamping
Transformer
Specifications:
X-Axis Travel: 28.7"
Y-Axis Travel: 20.1"
Z-Axis Travel: 20.1"
Distance From Table Surface to Spindle Gauge Plane: 130-640 mm
Table Height From The Floor To The Upper Face OF Table: 34.3"
Table (Pallet) Working Surface: 15.7" x 15.7"
Table (Pallet)
Loading Capacity: 660 Lbs.
Maximum Workpiece Swing Diameter: 27.5"
Maximum Workpiece Height: 17.7"
Maximum Spindle Speed: 12,000 RPM
Type of Spindle Taper Hole: No. 40 (HSK-A63)
Rapid Traverse Rate (X,Y): 50,000 mm/min
Rapid Traverse Rate (Z): 40,000 mm/min
Maximum Tool Diameter W/Adjacent Tools: 3.5"
Maximum Tool Diameter W/Out Adjacent Tools: 4.9"
Spindle Drive Motor: 24.7/20 HP
Electrical Power Supply: 35.6 kVA
Coolant Tank Capacity: 198 Gallons
Machine Height (From Floor): 128.5"
Floor Space: (width x depth): 109.2" x 155.5"
Mass of Machine (Approx.): 27,280#
Dealer: GIBBS MACHINERY COMPANY INC
Price request
