Technical details
Control: FANUC 16i-MA
Technical data
Table length: 1400 mm
Table width: 650 mm
Longitudinal travel (X-axis): 1250 mm
Transversal travel (y-axis): 700 mm
Vertical travel (z axis): 750 mm
Table load max.: 1500 kg
Pallets chanching device:
number: 2
Length: 1400 mm
Width: 650 mm
Time of changing palets: 45 sec
Transport weight: 1500 kg
Tool changer:
Number of tools: 40
Tool diameter: 120 mm
Diameter with free adjacent pockets: 200 mm
Tool lenght: 400 mm
Max. tool-weight: 20 kg
Time of tool changing: 5 / 11 sec
Spindle nose:: n° 50
Distance from vertical
spindle to table: 100/850 mm
Spindle speeds:
stepless
up to: 4000 rpm
Vertical spindle speeds:
stepless
from: 20 rpm
up to: 4000 rpm
Torque max.: 662 Nm
Rapid traverse:: 15 m/min
Voltage 50 Hz 3x: 400 Volt
Spindle motor: 26 kW
Machine's weight about: 16750 kg
Overall dimensions machine:
Length: 7135 mm
Width: 5300 mm
Height: 3266 / 2980 mm
Various accessories:
Full splash cabin
Coolant system
High pression colant device
Booster pump (coolant): 30 bar
Internal coolant supply (cts)
Chip conveyor
Electronic hand held remote control
Lamp
RS-232 Interface
Central lubrification
Dealer: MULLER MACHINES SA
Price request
