Tripet - MUS 100

Tripet - MUS 100
  • Tripet - MUS 100
  • Tripet - MUS 100
  • Tripet - MUS 100
  • Tripet - MUS 100
  • Tripet - MUS 100

Price request
  • BrandTripet
  • Type/ModelMUS 100
  • Stock Number18818
  • Price€ 000
  • WebsiteMUS 100

Technical details

  • Grinding diameter maximum mm
  • Grinding diameter minimum mm
  • Turning diameter mm
  • Grinding depth mm
  • CNC Brand
  • CNC Model


Technical data
Max. internal grinding diameter: 20 mm
Centre height: 60 mm
Distance between centres: 150 mm
Workpiece spindle speeds:
number (steps): 3
from: 560 rpm
up to: 1000 rpm
Spindle hole: 12 mm
Taper in spindle:: 12 W
Possible grinding-spindle speeds:
from: 6000 rpm
up to: 9000 rpm
Rotatable grinding spindle head (b-axis): +45 / -45 °
Voltage 50 Hz 3x: 380 Volt
Machine's weight about: 250 kg
Overall dimensions machine:
Length: 900 mm
Width: 750 mm
Height: 1300 mm
Various accessories:
3-jaw chuck diameter
Horizontal grinding spindle support
Set of flanges
Set of collets: W 12
Steady
External grinding spindle

Dealer: MULLER MACHINES SA
