Technical details
Control: ELAU PT1
Technical data
Max. drill depth: 600 mm
Drill capacity in steel:
up to diameter: 18 mm
Spindle stroke: 600 mm
Table length: 1375 mm
Table width: 700 mm
rotatable: 360 °
Max. loading: 2000 kg
Longitudinal travel (X-axis): 700 mm
Transversal travel (y-axis): 500 mm
Spindle speeds:
up to: 4000 rpm
Spindle nose SK: 40
Voltage 50 Hz 3x: 380 Volt
Spindle motor: 2.3 kW
Machine's weight about: 2800 kg
Overall dimensions machine:
Length: 4500 mm
Width: 1800 mm
Height: 2700 mm
Various accessories:
Drill chuck with internal cooling
Digital readout number of axis:: 2
Coolant system
Dealer: MULLER MACHINES SA
Price request
