Technical details
Deep hole drilling machine
Samag - TFZ 2L - 1000
4 side complete machining
Swiveling drilling and milling unit
DCM Dynamic Collison Monitoring
CAM-Model
QCK ( Quick Check Kinematics)
Transfer bore cycle (380-382)
90 Bar IKZ Coolant system
Extra ATC Tower 24 position (4 x 6) HSK 63
Double ballscrew construction
Clear tank 1650 L and Waste tank 1300 L
Chip conveyor
Max. drill Ø steel: 36mm
Drilling depth: 1250mm
X - Travel: 1600mm
Y - Travel: 1050mm
Z - Travel: 1100mm
W - Travel: 1600mm
Table load: 7000
Table size L x W / or ø:1500 x 1100mm
Spindle taper: HSK-63Mk
Power on spindle: 13kW
Speeds / ranges: 6000Rpm
Length: 8100mm
Width: 6300mm
Height: 4300mm
Weight: 31000kg
Dealer: MACH4METAL BV
Price request
