Price request

Technical details

  • Turning diameter1070 mm
  • Turning length4150 mm
  • Turret positions22
  • Positions ATC1
  • Number controlled axis4
  • CNC BrandSiemens
  • CNC Modelx

Multi-tasking latheDMG MORI - CTX delta 4000 TC
MACH-ID 9066
Make: DMG MORI
Type: CTX delta 4000 TC
Control: SIEMENS 840D
Year: 2012

Combine turning with 5-axis milling and simultaneous milling with five axes in one working space
Mill-Turn machine achieves complex geometries in one cycle as a combination machine
Apllivcation examples:
CrankShaft machining
Turbine Blade machining
Aerospase components
Boring bar internal machining like; pumps, housing, casting, turbines

Feed rate X Axis 40.000 mm/Min
Feed rate Y Axis 30.000 mm/Min
Feed rate Z Axis 32.000 mm/Min

Work load 7000 Kg not supported
Glas scales in Y and Z-Axis
Rensihaw 3D taster
Steady rest 1 from 125 to 460 mm
Steady rest 2 from  460 - 700 mm
Double Chuck SMW BHD 630 - 230
Large tooling package

Max. turning Ø:   1070mm
X-Axis:           1040mm
Y-Axis:           330 + 280mm
Z-Axis:           4150mm
Spindle bore:     230mm
Speedrange:       1500Rpm
Spindle power:    52kW
Subspindle speeds:1500Rpm
Subspindle bore:  230mm
Subspindle power: 52kW
ATC / revolver:   140
B-Axis Toolsystem:CAPTO C8
B-Axis Speedranges:12000Rpm
B-Axis power:     34kW
Length:           11780mm
Width:            4970mm
Height:           4300mm
Weight:           60000kg

Dealer: MACH4METAL BV
