Technical details

  • Table length4680 mm
  • Table width750 mm
  • Longitudinal X4200 mm
  • Cross Y750 mm
  • Vertical Z695 mm
  • Positions ATC33
  • CNC BrandHeidenhain
  • CNC Modelx

Bed type milling machineHedelius - Tiltenta T7-4200
MACH-ID 8502
Make: Hedelius
Type: Tiltenta T7-4200
Control: HeidenHain iTNC 530
Year: 2014

5 Axis Simutenious Machining
Heidenhain iTNC 530
Heidenhain HR 410 handwheel
Formingstar feed motor with Cyclus 320 ( vario Dynamic)
Coolant tank 900 Liter
M&H 3D measuring probe
Pendel screen
Direct Heidenhain scales


X - Travel:               4200mm
Y - Travel:               750mm
Z - Travel:               800mm
A - Axis:                 - 98 to + 98°
B - Axis:                 360000°
Table  Ø:                 750  ( Swing 1100)mm
Feed rate X-Axis:         40000mm/min.
Feed rate Y-Axis:         40000mm/min.
Feed rate Z-Axis:         40000mm/min.
Spindle Taper:            40ISO/Bt/Mk
Power on spindle:         29kW
Speeds / ranges:          14000Rpm
ATC / revolver:           33
Coolant true spindle / Bar:Yes 25 Bar
Number of controlled axis:5
Chip conveyor:            Yes
Coolantsystem:            Yes
Length:                   8900mm
Width:                    5100mm
Height:                   2730mm
Weight:                   24000kg

Einsatzgebiet:

Vertikalbearbeitung von langen Werkstucken
Stirnbearbeitung von lamngen Werkstucken
3/5 Achsen Bearbeitung in pendel betrieb mit trennwand
Wellenbearbeitung mit NC-Rundtisch
Endenbearbeitung
Vertikalbearbeitung
Wellem / Futterbearbeitung
